| PERFORMANCE |
| Processor |
Intel Core™ Ultra 7 255HX, 20C (8P + 12E) / 20T, Max Turbo up to 5.2GHz, 30MB Intel® Smart Cache
|
| AI PC Category |
AI PC, AI-Powered Gaming PC
|
| NPU |
Integrated Intel® AI Boost, up to 13 TOPS
|
| Graphics |
NVIDIA GeForce RTX™ 5060 8GB GDDR7, Boost Clock 2497MHz, TGP 115W, 572 AI TOPS
|
| Chipset |
Intel® HM870 Chipset
|
| Memory |
2x 16GB SODIMM DDR5-5600
|
| Memory Slots |
Two DDR5 SODIMM slots, dual-channel capable
|
|
Max Memory
|
Up to 32GB DDR5-5600 offering
|
| Storage |
1TB SSD M.2 2280 PCIe® 4.0x4 NVMe®
|
| Storage Slot |
Two M.2 2280 PCIe® 4.0 x4 slots
|
|
Max Storage Support
|
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB
|
| Optical |
None
|
| Card Reader |
No Card Reader
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3306 codec
|
| Speakers |
Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio
|
| Microphone |
2x, Array
|
| Camera |
5.0MP with E-shutter
|
| Battery |
80Wh
|
| Power Adapter |
245W Slim Tip (3-pin)
|
| Special Features |
AI Chip: LA3
|
| DESIGN |
| Display |
16" WQXGA (2560x1600) OLED 500nits (typical) / 1100nits (peak) Glossy, 100% DCI-P3, 165Hz, DisplayHDR™ True Black 1000, Dolby Vision®, G-SYNC®, Low Blue Light, High Gaming Performance, Flicker Free
|
| Touchscreen |
None
|
| Screen-to-Body Ratio |
91.7% AAR (active area ratio)
|
| Color Calibration |
Factory Color Calibration
|
| Pen |
Pen Not Supported
|
| Keyboard |
24-Zone RGB Backlit, English (UK)
|
| Touchpad |
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
|
|
Dimensions (WxDxH)
|
364.38 x 268.06 x 21.69-25.95 mm (14.35 x 10.55 x 0.85-1.02 inches)
|
|
Weight
|
Around 2.43 kg (5.36 lbs)
|
| Case Color |
Eclipse Black (with 24-Zone RGB Backlit Keyboard)
|
| Case Material |
Aluminium (Top), PC-ABS (Bottom)
|
| Surface Treatment |
Anodizing Sandblasting
|
| SOFTWARE |
| Operating System |
None
|
| Bundled Software |
None
|
| CONNECTIVITY |
| WLAN + Bluetooth |
Wi-Fi® 7, 802.11be 2x2 + BT5.4
|
| WWAN |
WWAN Not Supported
|
| Ethernet |
100/1000M (RJ-45)
|
| Standard Ports |
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
-
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort™ 2.1
- 1x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with DisplayPort™ 2.1
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Ethernet (RJ-45)
- 1x Slim tip Power connector
|
|
|
| SECURITY & PRIVACY |
| Security Chip |
Firmware TPM 2.0 Enabled
|
| Fingerprint Reader |
No Fingerprint Reader
|
| Other Security |
E-shutter
|
| SERVICE |
| Base Warranty |
1-year Warranty from Lenovo
|
